Hybrid Coupler HC0727-2I1O-INA

The Hybrid Combiner Product Description

The Hybrid Combiner is a key component in the field of RF passive signal processing. Its core function is to efficiently combine two RF signals or equally split a single signal, while offering excellent port isolation to effectively prevent signal crosstalk and ensure stable operation of the RF system. This model is suitable for signal processing in low-to-medium power applications, widely used in scenarios such as repeaters and indoor distribution systems. It supports efficient transmission and distribution of multi-band and multi-system signals. The Hybrid Combiner features low insertion loss, high isolation, wide frequency range, and low VSWR, making it ideal for wireless network optimization, Indoor Distribution System (IBS), Distributed Antenna System (DAS), and Antenna Feeder System (AFS).

Product Functions

1. Signal Combining and Splitting

·The 2x1 Hybrid Combiner: Combines or splits two signals, e.g., merging signals from two base stations into a single feeder line, or splitting one feeder line signal to two receivers.

2. Power Distribution and Combining

· Evenly distributes input power to multiple output ports, or combines power from multiple signals to enhance system capacity.

· Ensures accurate power distribution across ports, minimizing signal loss.

Product Features

1. Wide Frequency Range

· Supports 698–2700 MHz, meeting diverse application requirements.

2. Excellent Electrical Performance

· Low insertion loss and high isolation ensure efficient signal transmission.

3. High Reliability and Stability

· All-metal cavity structure provides strong shielding and outstanding anti-interference capability.

· Passive design with no active components, resulting in low failure rates and long service life.

4. Flexible Expansion and Compatibility

· Available in various configurations such as two-in-two-out and four-in-four-out, supporting multi-band and multi-system access.

· Standardized interfaces for easy integration and expansion.

5. Easy Installation and Maintenance

· Integrated heat dissipation and compact design with built-in cooling fins.

· Compact size, lightweight, and easy to deploy.

Application Scenarios

1. Communication Systems

· Signal distribution and combining in wireless network optimization, Indoor Distribution System (IBS), Distributed Antenna System (DAS), and Antenna Feeder System (AFS).

2. Microwave and Satellite Communications

· Power distribution and combining of signals to ensure long-distance communication quality.

3. Testing and Measurement Equipment

· Calibration and testing of RF systems to ensure equipment performance compliance.

4. IoT and 5G Communications

· Supports multi-band and multi-mode signal processing to meet high-speed, low-latency requirements.

Summary

With its excellent electrical performance, wide frequency range, compact design, and high reliability, the Hybrid Combiner has become an indispensable key component in modern RF systems. Whether in Indoor Distribution Systems (IBS), Distributed Antenna Systems (DAS), or testing instruments, it plays a vital role in ensuring efficient signal distribution and stable system operation.

The Hybrid Combiner, with its excellent electrical performance, wide frequency range, high reliability, and outstanding performance, is a critical passive component in wireless communication networks. Whether in Indoor Distribution Systems (IBS), Distributed Antenna Systems (DAS), or specialized communication scenarios, it effectively enhances signal quality, reduces interference, and optimizes network resources, serving as a core enabler for the efficient operation of modern communication systems.
