10dB Feed Coupler C0737-10PMI-DC 698-3700MHz

Product Description of Feed Coupler

The feed coupler is a high-performance passive RF device designed for signal coupling and power distribution in wireless communication systems. Its coupling port integrates a power feeding function, which can supply power to the circuit at the coupling output end. Its core function is to couple a portion of power from the main signal path to the coupling port for signal monitoring, power distribution or signal sampling, while maintaining extremely low intermodulation distortion. Widely used in scenarios such as base stations, repeaters and in-building distribution systems, it ensures signal transmission quality and system stability. The coupling port of the feed coupler features a power feeding function, and the output composite signal can supply power to composite antennas with different functions (Bluetooth positioning or IoT sensors) or downstream circuit equipment, solving the power supply problem of multi-stage devices connected to the coupler. The feed coupler boasts excellent performance in terms of low passive intermodulation (PIM), low insertion loss and high power handling capacity, making it suitable for wireless network optimization, in-building distribution systems (IBS), base transceiver stations (BTS), distributed antenna systems (DAS) and antenna-feeder systems (AFS).

Product Functions

1. Signal Coupling and Power Distribution

- Realizes power distribution between the main signal and the coupled signal, supporting signal monitoring, sampling and analysis.

- Ensures low-loss transmission of the main signal and high isolation of the coupled signal to meet diverse power distribution requirements.

2. Power Supply for Coupling Output Circuit

- Supplies power to the coupling output circuit, effectively resolving the power supply issue of multi-stage devices connected to the coupler.

- Enables systematic line power feeding, and the working status of each device can be detected in a timely manner through the line power detection system.

3. Enhancing System Reliability and Stability

- Generates extremely low intermodulation distortion (IMD), avoiding spurious signal interference and ensuring isolation between systems.

- Improves signal transmission quality, enhancing communication stability and network reliability.

4. Optimizing Network Resource Allocation

- Supports multi-band and multi-system access, compatible with mainstream communication standards.

- Provides accurate data support for signal monitoring, power control and fault diagnosis.

Product Features

1. Ultra-Low Intermodulation Distortion (IMD)

- Adopts a high-quality cavity structure and precision manufacturing process, with a typical third-order intermodulation (IM3) value of -160dBc@2×43dBm, far superior to industry standards.

- Effectively suppresses spurious signals and prevents system interference.

2. Excellent Electrical Performance

- Features low insertion loss and high coupling accuracy to ensure efficient signal transmission and sampling.

- Delivers high isolation, maintaining independent and stable operation of the main signal and coupled signal.

- The coupling port has a power feeding function, solving the power supply problem of multi-stage devices connected to the coupler.

3. High Reliability and Stability

- All-metal cavity structure provides strong shielding and outstanding anti-interference capability.

- Passive design without active devices ensures low failure rate and long service life.

4. Flexible Expandability and Compatibility

- Supports multi-band and multi-system access, compatible with mainstream communication standards including 2G/3G/4G/5G, Wi-Fi and IoT.

- Offers multiple coupling ratio options and supports cascade expansion to meet the requirements of different application scenarios.

5. Easy Installation and Maintenance

- Compact structure, small size and light weight facilitate easy installation and deployment.

Application Scenarios

1. Base Station and Repeater Systems

- Used for signal monitoring, power control and fault diagnosis to improve system stability.

2. In-Building Distribution Systems

- Applied in large-scale buildings such as shopping malls, office buildings, airports and subway stations for signal sampling and monitoring.

3. Microwave and Satellite Communication Systems

- Realizes signal power distribution and combining to ensure long-distance communication quality.

4. IoT and 5G Communication Systems

- Supports multi-band and multi-standard signal processing to meet the requirements of high data rate and low latency.

5. Test and Measurement Equipment

- Used for calibrating and testing RF systems to ensure that equipment performance meets the specified standards.

Summary

As a core passive device of wireless communication networks, the low-PIM feed coupler not only significantly improves network reliability and stability through efficient signal coupling and power distribution, but also effectively reduces signal interference and optimizes resource allocation, making it widely applicable to various communication scenarios. The power feeding function of the feed coupler can supply power to multi-stage devices connected to it, enable real-time detection of device working status, and further enhance system stability. Its high reliability, ultra-low intermodulation distortion and excellent overall performance make it an important guarantee for the efficient operation of modern communication systems.
